Johnson Pump
Johnson Pump Baitwell Pump - 5.2 GPM - 12V
SKU 49134·Livewell Pumps
$313.49
Aqua Jet Water Pressure Systems - 5.2GPM - 12VThe five chamber Aqua Jet WPS-series provides a reliable heart for small boat and recreational vehicle water pressure systems. Compared to conventional three or four-chamb...
1
Sold out
·Ships from US distribution
Authorized dealerGenuine Johnson Pump
Secure checkoutPowered by Shopify
Expert supportTalk to a rigger
Will it fit your boat?
Size it to your vessel first
Run your loads through the Energy Planner to confirm this gear covers your daily draw — and see if you need more panels or battery.
Open the Energy Planner →Aqua Jet Water Pressure Systems - 5.2GPM - 12V
The five chamber Aqua Jet WPS-series provides a reliable heart for small boat and recreational vehicle water pressure systems. Compared to conventional three or four-chamber diaphragm pumps, the Aqua Jet demonstrates dramatically lower noise and water pulsation characteristics. It is recommended to install the WPS-pumps with an accumulator tank. Always use a PUMProtector inlet strainer before the pump intake.
Diaphragm: Santoprene
Valves EPDM
Body: Nylon/Polypropylene
Motor: 150W
Pressure Cut Off:2.8 bar - 41psi
Fuze Size: 15 A
Connection:3/8" NPT/hose 1/2", 1/2"NPT/Hose 3/4", 1/2" NPT, 3/4" Hose
Weight: 2 kg /4.5lbs
Length: 236,5 mm/9.31"
Width: 210 mm/8.25"
Height: 116 mm/4.575"
The five chamber Aqua Jet WPS-series provides a reliable heart for small boat and recreational vehicle water pressure systems. Compared to conventional three or four-chamber diaphragm pumps, the Aqua Jet demonstrates dramatically lower noise and water pulsation characteristics. It is recommended to install the WPS-pumps with an accumulator tank. Always use a PUMProtector inlet strainer before the pump intake.
Diaphragm: Santoprene
Valves EPDM
Body: Nylon/Polypropylene
Motor: 150W
Pressure Cut Off:2.8 bar - 41psi
Fuze Size: 15 A
Connection:3/8" NPT/hose 1/2", 1/2"NPT/Hose 3/4", 1/2" NPT, 3/4" Hose
Weight: 2 kg /4.5lbs
Length: 236,5 mm/9.31"
Width: 210 mm/8.25"
Height: 116 mm/4.575"
BrandJohnson Pump
SKU49134
UPC729321917919
TypeLivewell Pumps
Weight8.25 lb
