ASEA Power Systems 12 kVA Isolation Transformer
12 kVA Isolation TransformerASEA’s Isolation Transformer is a drop-in replacement for Charles IsoG2, designed to protect vessel under-fittings from galvanic corrosion and to shield onboard electronics from reverse pol...
Size it to your vessel first
Run your loads through the Energy Planner to confirm this gear covers your daily draw — and see if you need more panels or battery.
Open the Energy Planner →12 kVA Isolation Transformer
ASEA’s Isolation Transformer is a drop-in replacement for Charles IsoG2, designed to protect vessel under-fittings from galvanic corrosion and to shield onboard electronics from reverse polarity and shore power fluctuations. It also ensures safety by preventing the boat from sending unintended electric currents into the surrounding water.
Features:
- Ignition-protected, safe for gasoline-powered vessels
- Complete Electrical Isolation prevents dockside ELCI breaker trips
- Maintains a safer marine environment by mitigating the risk of ESD
- Ensures clean and stable AC power for on-board equipment
- Reduces galvanic corrosion
- Meets the latest NEC 555.35 marina code that ensures GFPE limits are not exceeded
Specifications:
- Input Voltage: 240VAC
- Input Current: 50 A
- Output Voltage: 240VAC
- Output Current: 50 A
- Output Frequency: 60 Hz
- Weight 160 lbs
- Height: 27cm / 10.6 in
- Width: 26cm / 10.2 in
- Width (with flange): 33 cm / 13 in
- Depth: 26.7 cm / 10.5 in
Certifications:
- ABYC E-11 Compliant
- ABYC C-1500 (for ignition protection)
- UL 1500 (for ignition protection)
- UL 1561
Good to know
- Genuine ASEA Power Systems product from an authorized dealer.
- Ships from US distribution.
- Questions about fit or installation? Contact us before you order.
